Fully Automated Fleet Fueling: Why You Should Consider It

Posted by SM2 Superfan on 3-Nov-2021 10:00:00 AM

"Workaholics aren't heroes. They don't save the day, they use it up. The real hero is already home... Because she figured out a faster way to get things done."

— Jason Fried and David Heinemeier Hansson

Fleet managers with business acumen know the importance of not just working hard, but also working smart. And yet, when it comes to fuel management, many fail to reap the full promise of automated fuel management systems.

Still, automation done wrong will decidedly do more harm than good to your fuel management efforts. In this edition of Fleeting Thought, we make the case for fully automated fueling but, just as important, we address some of the pitfalls you may face in deploying this rewarding technology.

Fuel Management Systems—The Basic Premise

We have covered fuel management systems for fleets in depth in a previous blog post; notwithstanding some minor variations, the basic premise generally goes something like this: users in need of fuel drive up to a pump only to find it locked by the system. To get access to fuel, properly credentialed users authenticate themselves and, optionally, their vehicle to the system. This is typically done on a Fuel Island Terminal permanently mounted near the dispenser(s).

Standard configurations will use some combination of the following authentication methods:

  • Manual PIN input via keypad
  • RFID cards
  • RFID key fobs
  • Mag stripe card (obsolete due to poor reliability)
  • Optical punched cards (obsolete due to poor reliability)

Unquestionably, fleets with in-house fueling facilities and/or fuel trucks need, and almost invariably have, a fuel management system. However, a number of commonly encountered issues can erode the rewards you (justifiably) expect from your investment.

Let us take stock of them here and determine how to tackle them.

Fuel Management Systems—Some Weak Linkschain with paper clip as a link fuel management system weaknesses

Operational Friction

A nearly universal law of any tracking and management system is the introduction of extra steps into the business process and fuel management is no exception. Regrettably, the concerns and motivations of system users and system owners/managers don't always align. Here again, fuel management is no exception.

Drivers, operators, and floor staff sometimes don't have the patience for it. Shortcuts may be taken. Misallocation, misattribution, and general mismanagement ensue in the name of expedited refuelling.

Common ways of bypassing important fueling steps include:

  • Inputting inaccurate data simply because it's easier to key in ("00000" for vehicle mileage, for instance)
  • "Passing the nozzle forward" to the next person in line without closing out the transaction (i.e., just re-cradling the dispenser nozzle), thus bypassing the second user's authentication entirely
  • PIN or card sharing
  • Switching the system to bypass mode unnecessarily
The unhappy result: loss of tracking and accountability, bad data in need of cleansing, recurring and unprofitable administrative chores, and so on. Clearly not the kinds of impact you hope for when deploying technology.

Cheating the System

In a world where technology is ubiquitous, it's not uncommon for users to try and circumvent a new control system. This is sometimes motivated by a desire to escape "Big Brother's" watchful eye, but other more nefarious motives—such as fuel theft—are also in the mix.

Nonetheless, control, track, and manage that valuable fuel we must in service of both the planet and profits. We can't help but note that nonautomated vehicle authentication methods harbor serious trouble for the integrity of an otherwise fine fuel management system.

The problem is that once a legitimate vehicle number is keyed in, the system has no means of knowing whether or not the vehicle is physically present. Tagging the vehicle with RFID, combined with a long-range roadside or overhead reader, improves the situation somewhat since the system can now verify actual vehicle presence. But even in this case, the opportunity remains for pumping fuel into a different vehicle instead of (or in addition to) the approved company asset.

Multiple Tanks

To err is human, and to forgive is divine. Even so, in some cases, all the forgiveness in the world won't offset the budget-busting consequences of pouring the right product into the wrong fill pipe.

Every vehicle has many fill pipes for different fluids used by various vehicular systems. This is normally not a problem since they are readily distinguished by their size, form, or location. But many classes of industrial equipment—found notably in public works, construction, mining, et al.—are designed to have multiple fuel or hydraulics tanks that accept very different products yet might easily be mistaken for one another.

Since basic fuel management systems have no way to discern which fill pipe the nozzle is inserted into, a distracted worker may well dispense diesel into, say, the hydraulic tank port of a high-priced piece of machinery with pretty devastating consequences.

Fully Automated Fleet Fueling to the Rescuetwo gears engraved with process automation coencorp sm2 automated fleet fueling

The fundamental idea

The remedy to these issues is a system able to authenticate the vehicle (thereby confirming its presence) automatically and verify that the dispenser nozzle is physically inserted into the fill pipe. Both conditions must be true for fuel to flow and keep flowing: remove the nozzle and the flow is interrupted, keeping everyone honest—and limiting spills to boot.

This rightly so-called fully automated fleet fueling is generally achieved using an RFID tag and reader working in tandem; one component is mounted on the nozzle and another near the vehicle's fill pipe, with the reader detecting the tag whenever they are in close enough proximity. This guarantee of the physical proximity of the nozzle to the fill pipe is the key element in achieving theft prevention with fully automated fueling.

In such setups, the user drives up to the dispenser, inserts the nozzle into the vehicle fill pipe, and the pump is immediately unlocked. Fueling begins (provided the vehicle is approved and compatible with the product being dispensed).

We can see how the previously listed difficulties are overcome:

  • Operational friction is eliminated as there is no longer a need to identify the vehicle and the desired hose manually.
  • Cheating the system becomes far more difficult since tampering with the automation hardware keeps the dispenser locked.
  • The system can guarantee that even the most distracted worker can never pump a product into an incompatible tank.

Nozzle gear: active vs passive

Astute readers will have noticed that in describing the "RFID reader and tag" scheme above, we didn't mention which of the reader or tag is attached to the nozzle and which is at the fill pipe. It turns out that this design decision matters, and the difference it makes isn't trivial.

Given that in all cases, without exception, there are many more vehicles than dispensers involved, locating the lower-priced component, the tag, on the vehicle seems like the obvious call. Further, RFID tags have a virtually infinite lifespan, and they are passive, eliminating the need to provide a power source. And mounting a suitably packaged RFID reader on the dispenser nozzle doesn't seem to pose any problems either. This so-called "active nozzle gear" does need electrical power, but even very old or basic dispensers have AC power at the very least.

However, outcomes from real-world deployments reveal significant downsides to this configuration. These downsides bring about costs which, while not paid upfront, are quite tangible and which we believe justify the opposite design decision.

downsides of active nozzle gear

Although saving money on initial deployment looks appealing on paper, active nozzle gear doesn't generally do well in private fleet operations, a predicament further aggravated in harsh environments. Worth keeping in mind: when the vehicle-side device fails, just one vehicle is impacted; when the nozzle-side device fails, nobody can get fuel.

So what are the chief downsides of having active nozzle gear?

Using the pump to power, the nozzle gear has serious issues: Dispenser power has to be tapped and routed along the hose to the nozzle where it's needed, necessitating special wiring and fittings, which should (but don't always) come in various versions to accommodate a plethora of dispenser makes, models, and years. These parts can't be procured off-the-shelf from generic distributors, significantly raising the cost of ownership with every repair/replacement. Also, mechanical-type industrial dispensers run on AC power alone, which must be converted to clean DC, raising the cost, size, and weight of the nozzle gear while lowering its reliability. All of this must meet intrinsic safety regulations, upping the cost of any solution yet a few more notches.

And last but not least, that special cable running along the dispenser hose and into the nozzle is an invitation to vandalism, notoriously in times of workplace turbulence.

Battery-powered nozzle gear introduces its own set of problems: A battery-powered design solves these issues but introduces different ones. Batteries need regular recharging and replacing, neither of which is desirable or even practically feasible in a fleet fueling context; this headache is exacerbated in cold or hot environments. Moreover, intrinsically safe designs often mean potted modules that cannot be serviced when damaged or spent and are, therefore, disposable. Some fueling sites are remote and potted modules with internal batteries have, by definition, a limited shelf life, which makes stocking up for quick replacement an unattractive option.

Finally, a more subtle yet quite disruptive problem lurks: the intermittent "now it works, now it doesn't, now it works again" behavior that occurs as the voltage output of deteriorating batteries gradually falls into the grey zone of marginal compliance for the circuitry its powers. Anyone who's owned a TV remote knows how irritating that can be, imagine how much worse it is when trying to fuel up and get on with your work day. On a very hot, cold, or rainy day.

Active devices are innately more failure-prone than passive ones: Powered components, more components, and greater device complexity add up to more points of potential failure. Fuel pump nozzles are often mistreated; we've seen them used as hammers and scrapers against ice buildup around fill pipes. They might get dropped on the ground or run over by accident. Therefore battery operated nozzle devices tend to fail prematurely, not to mention degraded battery performance in cold climates.

On the whole, active nozzle gear might do a reasonable job in retail fuel settings but the more severe treatment dished out by fleet environments (and people!) yields an unacceptably high cost of ownership garnished with needless complications. As a commercial or industrial fleet manager considering fully automated fueling, you will definitely want passive nozzle gear technology.

Automated Fleet Fueling: A Worthwhile Investmenttoy loader next to calculator and piles of coins coencorp automated fueling smart investment

When considering fully automated fleet fueling, most businesses reflexively question whether or not they can afford it, a healthy reaction of course. But when such initiatives can eliminate fraud and minimize mistakes while also saving time and reducing friction in business processes, an equally worthy question should be, "Can we afford not to do it?"

Automating your fleet fueling operations is clearly a worthwhile investment. Proceed carefully, and you will easily avoid a few pitfalls along the way.

Working smart is as important as working hard, if not more. Being the hero who gets things done and goes home beats being the workaholic burning the midnight oil any day in our book.
